The Official Nintendo Switch 2 AC Adapter is the primary power supply manufactured by Nintendo. It is specifically built to power the console in handheld mode or supply enough power to the Nintendo Switch 2 Dock to handle 4K TV output.
Unlike the previous generation’s fixed-cable charger, the Switch 2 power adapter features a detachable USB-C to USB-C cable for easier pack-up and travel.
Key Features & Functionality
- 60W Power Delivery (PD): The adapter maxes out at 60 Watts via standard USB-C Power Delivery. This is a massive upgrade over the older console’s 39W limit to match the power needs of the upgraded next-gen hardware.
- TV Mode Requirements: The Switch 2 dock relies heavily on this official profile. Third-party bricks under 54W often trigger a “charge-only fallacy,” meaning they charge the handheld but fail to push video to your TV.
- Smart Power Control: Even though the block outputs up to 60W, the console safely regulates heat by drawing roughly 11W to 17W during basic handheld charging to protect the battery lifespan.
- Detachable Long Cable: Includes a high-grade, 1.5-meter (5-foot) detachable USB-C power cable.
Technical Specifications
- Input Power: AC 100V – 240V ~ 50/60Hz, 1.6A (Dual voltage for global travel)
- DC Power Output Profiles:
- 5.0V ⎓ 3.0A (15W basic USB)
- 9.0V ⎓ 3.0A (27W fast charge)
- 15.0V ⎓ 3.0A (45W standard dock power)
- 20.0V ⎓ 3.0A (60W maximum ceiling)
- Physical Dimensions: Roughly 49.5 mm x 38.5 mm x 45 mm
- Connection Port: Type-C USB
